Imperial code VS metric code SMD components sizes
 - what is the difference between the SMD sizes?

What is the SMD size code difference between 0201 component imperial code vs metric code

It can cause some confusion, but it's actually very simple, as the number code on the component is the component size. This is the case both with Imperial or metric code:

  • Imperial code is in inches
    Example: 0201 imperial component.
    This means that the component is 0,02 x 0,01 inches.

  • Metric code is in millimeter
    Example; 0201 metric component.
    This means that the component is 0,2 x 0,1 mm in size.

    Component size compare:  008004" imperial = 0201 metric code

Share SMD size info

Share



— Imperial code VS Metric code - SMD size code chart —

To help you understand the difference in size between Imperial components & Metric component
- we have made this visual SMD components size chart.


SMD size chart - free download >

SMD size chart with SMD size code in Imperial and Metric. Download this SMD size chart.

SMD size chart - free download >

Also check out the YAMAHA SMT software​

Software features >

SMD component sizes translation Metric VS Imperial

This overview shows you a selection of components that is the same size, but have different names depending on if it's named in Metric code or in Imperial code.

SMD components can be measured in either imperial or metric code

Metric code component
compared to
Imperial code component
0201
 = 008004
03015
 = 009005
0402
 = 01005
0603
 = 0201
1005
 = 0402
1608
 = 0603
2012
 = 0805
2520
 = 1008
3216
 = 1206
4516
 = 1806
4532
 = 1812
5025
 = 2010
6332
 = 2512

0201 Imperial compared to 0201 Metric component size

As a SMT machine supplier we understand how crucial it is that you know the difference. We take pride in giving our customers the correct guidance to make their basis for decision the best possible.

So when we tell you that YAMAHA YRM20 pick & place supports 008004" / 0201 component in metric code - do you know how tiny 0201 SMD component in metric is?

Access to expert guidance >

Your Dynamic Snippet will be displayed here... This message is displayed because you did not provided both a filter and a template to use.

How small components do
YAMAHA Pick & Place machines support?

YAMAHA Pick & place supports the tiniest components

With the right configuration of mounting head and nozzle for component pick-up the the Yamaha pick & place machines supports:

  • 008004"  (0201 mm) components.
