Yamaha SMT Production assistance package

Smart setup and operation of PCB assembly line
with Yamaha YsUP software

YAMAHA SMT Production assistance package

YAMAHA SMT YsUP software provides you with the smart setup operations and production monitoring all designed to assist to eliminate errors and the lift your production to efficiency.

The YAMAHA YsUP software is YAMAHA SMT's new software platform.

Setup error free with setup verification

Advanced YsUP productions assistance software combined with barcode technology enable you to setup for new jobs with:

  1. Verified  components

  2. then load & setup components on verified feeder

  3. and finally place feeder on verified position on Pick & Place machine or feeder cart.

The 3 easy steps above prevent incorrect component mounting and eliminate feeder position errors.

In clever collaboration with the programming & scheduling package the setup for a new job can be scheduled to optimize into ‘component group setups’ that support multi-PCB assembly production.

Instead of 1 setup for every single job – 1 ‘component group setup’ can be used for multiple jobs. Resulting in time saving setups.

YAMAHA YsUP production assistance include setup verification on the setup station
Setup verification on the YAMAHA setup station
Prevent the usage of expired SMD in your PCB assembly production

Prevent the usage of expired SMD

The YsUP production assistance package offers a ‘Material time limit management’ function that checks SMD inventory information during setup e.g., for MSD (moisture sensitive devises) remain time and solderability.

‘Material time limit management’ will give you warnings based on the defined inventory information that can prevent the usage of expired components and other devices that has exceeded defined time limits.

Intelligent components supply

Experience the optimum production flow with the ‘remaining components counter’ function, that:

  • Counts remaining components on each feeder during production

  • Requests re-supply of components before the P&P runs out

While the assembly line is running production the ‘remaining components counter’ is keeping track of how many components are left on each feeder, and lets you know when a re-supply of components is needed before the Pick & Place machine runs out.

Smart operation function. Define and setup a limit value for each reel that will prioritize a component re-supply for the reel splicing process.


Remaining components count monitors

Give the operator a better overview with the remaining components count on a monitor in the production area or on a mobile device even from remote locations. The remaining components counter is internet based and accessible by a web browser.
